Boom/Stick Excavator Option 1
| Max Cutting Height | 14 ft (4 m) |
| Max Digging Depth | 10 ft (3 m) |
| Max Loading Height | 11 ft (3 m) |
| Max Reach Along Ground | 16 ft (5 m) |
| Shipping Height of Unit | 8 ft (2 m) |
| Shipping Length of Unit | 14 ft (4 m) |
Dimensions
Jcb 803 Plus Operating Manual Pdf
| Height - Top of Cab | 8 ft (2 m) |
| Tail Swing Radius | 5 ft (1 m) |
| Width to Outside of Tracks | 5 ft (1 m) |
Engine
| Displacement | 91 cu in (0 m) |
| Engine Model | 403-15 |
| Gross Power | 28 hp (21 kw) |
| Max Torque | 68 lbs/ft |
| Net Power | 27 hp (20 kw) |
| Power Measured @ | 2,200 rpm |
| Torque Measured @ | 2,000 rpm |
Operating Specifications
| 12 | 12 V V |
| 55 | 55 A |
| Engine Oil Capacity | 1 gal (5 l) |
| Fuel Capacity | 13 gal (48 l) |
| Hydraulic Pump Flow Capacity | 8 gal/min (29 l/min) |
| Hydraulic System Fluid Capacity | 19 gal (70 l) |
| Hydraulic System Relief Valve Pressure | 2,756 psi |
| Operating Weight | 14,793 lbs (6,710 kg) |
Swing Mechanism
Undercarriage
Jcb 803 Plus Operating Manual Troubleshooting
| Ground Pressure | 5 psi |
| Max Travel Speed | 2 mph (4 kph) |
| Number of Track Rollers per Side | 4 |
| Shoe Size | 9 in (23 cm) |
